CCG is recognised worldwide as a major manufacturer of specialised cable glands and junction boxes, employing over 140 people.

CCG revolutionised the cable gland industry when it launched its much acclaimed ingress and corrosion proof Posi range, closely followed by the innovative patented corrosion guard cable gland. With these unique products CCG built an enviable reputation in Australia, Middle East, United Kingdom, Hong Kong, Malaysia and South Africa.

CCG's policy of building in safety and designing out complexity has lead to discerning engineers worldwide recognising CCG's products as time saving and waste reducing. The simplicity of the Captive Cone and Built-in Seals means that wherever CCG products are installed, the simplest of instructions ensure that all parts are correctly fitted. This concept is important for projects in the developing world, where semi-skilled labour may be used.

Within Australia, CCG has supplied products to the following prestigious projects:

• BHP Slab & Plate Plant, Port Kembla
• BHP Sulphate of Ammonia by-products
• CRA Westcliff
• BHP DRI Project, Pilbara, WA
• Western Mining, Leinster Gold Mine
• Mt Newman Mining, Newman
• BHP Minerals, Beenup Mineral Sands
• Gladstone Port Authority
• Transfield Engineering
• Underwater Video
• Griffin Coal
• Mt Isa Mines

CCG Australia Pty Ltd is ISO 9002 accredited and our range of products have British, European CENELEC, I.E.C., South African and Australian Standards where applicable.

Information necessary for correct gland selection

• Environmental conditions (e.g. hazardous areas, indoor or outdoor application).
• Cable type and voltage rating (armoured or unarmoured).
• Actual cable diameter overall, and under armour (bedding).
• Size and type of armour.
• If earth bound attachment is required.
• Outer sheath diameter should be used for selecting gland size.
• Assistance on selection is available on request.

The Range

CCG A2 Compression Gland – for flexible Cable

Gland Description

• For indoor/outdoor use.
• Seals on the cable sheath, to IP68 if fitted with a gasket.
• Specially formulated elastomeric seals.
• Precision manufactured from high quality brass and nickel plated.
• Complete with high quality brass locknuts.
• Also available in aluminium on request.

CCG BW Corrosion Guard – for PVC SWA PVC Cable

Gland Description

• For use in highly corrosive or wet locations.
• Cable gland manufactured from high quality brass and nickel plated.
• The screw-on Corrosion Guard is manufactured from non-corrosive material to protect the steel wire armour and metal parts of the gland.
• Corrosion Guard screws onto the gland body and seals over the outer sheath of the cable - giving an IP68 seal.
• Complete with a brass locknut and polypropylene gasket.

CCG CW Captive Cone Gland – for PVC SWA PVC Cable

Gland Description

• For outdoor use.
• Two piece handling, no loose parts.
• Freely rotating captive cone, providing an armour clamp and earth bond without twisting the steel wire armouring.
• By removing the outer nut and bushes, the inners of sizes 1 to 4 can be used as metric reducers.
• Provides a seal on the outer sheath of the cable - sealing to IP66.
• Also available in aluminium on request.

CCG Utility Box – General Purpose Junction Box

Utility Box Description

• Connection box for all surface applications.
• Manufactured from impact, corrosion, and UV resistant - glass reinforced polyester compound.
• Screw-on lid allows ease of installation.
• Locked with a special key, prevents unauthorised tampering.
• No exposed metal parts.
• Dust and water tight to IP68, when fitted with CCG sealed glands.
• One box gives 1-,2-, 3- or 4-way versatility (reduced stock holding).
• 4 blanking plugs provided.
• No drilling or tapping of cable entries required.
• Internal earth continuity ring and earth stud provided.
• Mounting studs provided for DIN rail, if using CCG terminal blocks.

CCG Foundation / Roof Entry Box – General Purpose Junction Box

CCG Foundation Box - For municipal connections.

Foundation Box Description

• For municipal service connections.
• Manufactured from impact, corrosion, and UV resistant - glass reinforced polyester compound.
• Screw-on lid provides ease of installation.
• Locked with a special key, prevents unauthorised tampering.
• Integral cable gland and lid seal, provide dust and waterproof seal.
• Knock-out holes provide for conduit entry at rear of box.
• Internal earth connector provided.

CCG Roof Entry Box - For overhead service connections.

Roof Entry Box Description

• For overhead single phase service connections.
• Manufactured from non-conductive, non-corrosive, UV resistant - glass reinforced polyester compound.
• Screw-on lid allows ease of installation.
• Locked with a special key, prevents unauthorised tampering.
• Box is mounted through corrugated iron, or asbestos type, roof sheeting.
• Roof entry sealed by rubber bush.
• Terminal connectors and integral earth connector supplied with box

CCG 4 Way / Y Junction Box – Exe, Exn, DIP, IP68

4 Way / Y Box description

• For use in surface hazardous areas and general industrial electrical installation.
• Manufactured from impact, corrosion, and UV resistant - glass reinforced polyester compound
• High temperature resistance and anti-static properties (black boxes only).
• Screw-on lid allows ease of installation.
• Locked with a special key, prevents unauthorised tampering.
• No exposed metal parts.
• One box gives 1-,2-, 3- and 4-way versatility (reduced stock holding).
• 4 blanking plugs provided.
• No drilling or tapping of cable entries required.
• Internal earth continuity ring and earth studs provided.
• DIN rail mounting studs are provided for use with CCG terminal blocks.
• Raised domed lid facilitates connections to be made outside of the box.
• If boxes used in hazardous areas, only approved CCG Exe glands and CCG Exe non-sparking terminals must be fitted.
• Dust and water tight to IP68, when fitted with CCG sealed glands.
• Can be buried for extended periods.
• Boxes with see through polycarbonate 'adapt-a lids' available on request.
• 4 way H-boxes with parallel entries available on request.

CCG Adaptors

PG threads (DIN German Standards)

• Because electric apparatus could generate from overseas countries, various foreign threads are encountered.
• It is, therefore, necessary to fit such threads with the appropriate adaptor.
• Although glands can be manufactured with special threads, it still leads to the problem - that if the gland is replaced at a later stage, the problem with the foreign thread entry remains.
• An adaptor, however, can stay permanently in place.
• Equipment originating in Germany, Switzerland, and most European countries is supplied with a PG thread.
• The letters PG stand for "Panzerrohr Gewinde".

NPT Adaptors Ex – Type A and B B

NPT threads National Piper Taper (USA)

• Because electric apparatus could originate from overseas countries, various foreign threads are encountered.
• It is, therefore, necessary to fit such threads with the appropriate adaptor.
• Although glands can be manufactured with special threads, it still leads to the problem - that if the gland is replaced at a later stage, the problem with the foreign thread entry remains.
• An adaptor, however, can stay permanently in place.
• Since the sizes 1/2"NPT-, 3/4" NPT-, 1"NPT, are close to I.S.O. metric threads, it is easy to mistake them as such. An interface between NPT and metric will, however, not form a flameproof path, and fitting a gland directly could lead to disaster.

CCG Accessories

CCG Shrouds

• CCG Neoprene Shroud
• CCG PVC Shroud
• CCG PVC Long Shroud

CCG Earth Tags

• CCG Slip on Earth Tag
• CCG Screw on Earth Tag

CCG Connection Sleeve

• CCG Terminal Connector
• CCG Insulation Sleeve

CCG Lock Nut

• CCG Brass Lock Nut

CCG Gasket

• CCG Sealing Gasket - Metric
